Hermod+ is an advanced sequencer for electronic music that maintains the format of its predecessor, Hermod, while introducing numerous improvements.

It allows the recording of CV/Gate, MIDI notes, and modulations on 16 polyphonic tracks.

Technical sheet

Sequencer
- Tracks: 8 CV/Gate + 8 MIDI
- Patterns: 16 per track
- Recording resolution: 96ppqn (5.2ms at 120 BPM)
- Effects resolution: 384ppqn (1.3ms at 120 BPM)
- Track length: from 1/16 note to 16 bars
- Pattern automations: CC modulation + pitchbend + aftertouch + sustain
Projects
- Number of projects: unlimited
- Tempo: 10 to 280 BPM
- Global transposition track: yes
- Dual-project architecture: yes
- Song length: 64 sequences
Piano-roll
- Minimum zoom: /4 (1 step = 1/4 note = 1 beat)
- Maximum zoom: X8 (1 step = 1/128 note)
- Note/gate duration: from 1/32 (1/512 note) to 8 bars
- Maximum polyphony per step: 24 notes
- Polyphonic editing: yes
- Timbre: C0 to C10
- Velocity: 0 to 127
Synchronization speed
- Max input speed: 1/96 = 24ppqn
- Max output speed: 1/96 = 24ppqn
- Audio synchronization from DAW (sample-accurate)
Inputs
- MIDI: TRS type A + USB host + USB device
- CV: 4x [from -5V to +5V]
Outputs
- MIDI: TRS (type A) + USB host + USB device
- CV : 8x [from -5V to +5V]
- GATE: 8x [0V / +5V]
- Output standards: V/octave (Eurorack), 1.2V/octave (Buchla), Hz/V (older synths)
Clock
- Dedicated clock port
- Dedicated clock reset port
Power supply
- Eurorack +5V rail configurable via rear switch
- Consumption (with +5V rail) : -12V 20mA, +12V 20mA, +5V 600mA (+500mA max via USB host)
- Power consumption (without +5V rail) : -12V 20mA, +12V 300mA (+220mA max via USB host), +5V 0mA
Dimensions & Weights
- Width: 26HP
- Depth: 20mm
- Weight: 285g (0.63lbs)
Technical specifications
- CV input resolution: 16-bit
- CV output resolution: 16-bit
- Displays: OLED 58x16mm
- SD card: microSD high speed (included)
- Processor: ARM 480MHz
