Preamp

Designed, built, and extensively "ear-tested" by long-time recording industry veterans, the A-Designs Pacifica takes its sonic signature and name from the revered Quad Eight mixing console. However, the A-Designs Pacifica has a sound and character all its own.

Technical sheet

Type of preamp Transistor

Two-channel, solid state preamp with two front-panel Hi-Z inputs.
Captures the sound quality of the legendary Quad Eight Pacifica console with even more presence and high-end.
Very warm and full tone without being dark; wide bandwidth with a sweet top end.
Custom-wound Cinemag input and output transformers.
Input transformer: A-Designs proprietary input transformer with unique winding.
Output Transformer: A-Designs proprietary alloy using the same massive design as the original Quad Eight.
72dB of quiet gain, great for use with ribbon mics.
Unique D.I. design sends signal through the input transformer for two transformers in the signal path.
Balanced XLR I/O.
Phase reversal (each channel).
-20dB pad (each channel).
+48V phantom power (each channel).
Solid construction, handmade in the USA.
Frequency response: 9Hz-101KHz.
Input impedance: 1500 ohm
Gain range: 72dB.
Noise (EIN): -128dB.
Phantom power: Switchable 48V.
Mic input phase: Switchable 0 -180°.
Instrument Input Jack 1/4''
Output: Balanced XLR
Distortion: Less than 1%.
Power requirements: 100/120/230 VAC - 23W.
Dimensions: 19'' x 1-3/4'' x 10''
Weight: 11 lbs.
Shipping weight: 12.5 lbs.
