For over 10 years, Antelope has been offering the best clocks on the market. The manufacturer lives up to its reputation with this OCX-HD model.

This device boasts a sampling frequency of up to 768kHz.
It integrates the latest generation AFC technology, based on an algorithm managing jitter with a thermo-controlled crystal oscillator.
Multiple synchronization possibilities are available thanks to various connection formats: 10 paired WC BNC outputs, 4 AES/EBU outputs, and 2 S/PDIF outputs.
Its extensive connectivity makes it the most versatile clock in its category.
It includes 2 WC inputs, a video synchronization input compatible with most SD and HD formats, synchronization distribution, and a varispeed function.
It features a 10MHz input allowing synchronization with the new Antelope atomic clock: 10MX.

With a sampling frequency of up to 768kHz, OCX-HD offers optimal precision for your audio recordings.

With Antelope's AFC technology, you benefit from advanced jitter management for clearer and more stable audio signals.

The multiple connection options of OCX-HD provide great flexibility to integrate this clock into your existing audio setup.

In addition to its basic features, OCX-HD offers advanced options such as the varispeed function and synchronization with other Antelope equipment.

Antelope's OCX-HD is an ideal choice for audio professionals seeking precision and versatility in their setup.

With a high sampling frequency and advanced technologies, OCX-HD offers exceptional performance for precise synchronization of your audio equipment.
Its extensive connectivity and advanced features make it a wise choice for professional studios and high-quality installations.
With OCX-HD, Antelope continues its tradition of excellence by offering a benchmark clock for demanding audio applications.

Sync System
- 4th generation Acoustically Focused Clocking (AFC)
- 64-bit DDS
- Thermo-controlled crystal oscillator
- Clock stability: +/- 0.02 ppm, thermo-controlled at 64.5 C/148.1 F
- Clock aging: 1 ppm per year
- Clock calibration: +/- 0.001 ppm
- Atomic clock input: 10 MHz
- Generated sampling frequencies: 32, 44.1, 48, 88.2, 96, 176.4, 192, 352.8, 384, 705.6, 768kHz
Master Clock Outputs
- 10x WC outputs up to 768kHz
- 4x AES/EBU outputs up to 192kHz
- 2x S/PDIF outputs up to 192kHz
Inputs
- 2x WC inputs up to 768 kHz
- 1x video input supporting various SD and HD video signal formats
- 1x atomic input
- 2x S/PDIF inputs up to 192kHz
- 1x AES/EBU input up to 192kHz
- 1x USB port for control
Power Supply
- Universal AC Input~95-245V, 20 Watts Maximum
Operating Temperature
- 0-50 C / 32-122 F
Weight
- 2.65 kg/ 5.84 lb
Dimensions (per unit)
- Width: 482.6 mm / 19"
- Height: 44 mm / 1.75"
- Depth: 230 mm / 9.05"
In the Package
- Isochrone OCX HD
- Warranty Card
- User Manual
- 1x USB Cable
- 1x Power Cable
