Asm Hydrasynth Deluxe

1639.00 €
IN STOCK - shipped under 2/3 days
  • Need help +33 1 81 930 900

  • Fast delivery

  • Guarantee : 3-years warranty

    days refund guarantee : within 30 days



The Hydrasynth Deluxe offers a dual synth engine configuration for a total of 16 voices of polyphony. Featuring a high-end 73-note keyboard with ASM's PolyTouch® (polyphonic aftertouch) feature, puts it in the top tier. The Deluxe is essentially two Hydrasynths in one instrument;
KeySplit and Dual voice mode patches with 8 independent voices are possible.
Separate balanced stereo audio outputs are available for each of the two parts. The easily accessible 4-octave ribbon controller provides a truly expressive dimension that is rarely equalled. The Hydrasynth Deluxe of course offers CV/GATE inputs/outputs for interfacing with the
CV/GATE inputs and outputs for interfacing with modular and other voltage-controlled synthesizers.
There's a ton of creative potential in this instrument, with ASM's WaveScan oscillators, Mutator waveform section and user-configurable filters. A
plethora of LFOs and envelopes, plus numerous insert and master effects.
The Hydrasynth Deluxe is a dream synth and without a doubt the ultimate live controller.


Ref : 99808
- Number of keys :
- Touch : light touch
- Type of synthesizer : numerical modeling
- 16-voice polyphonic digital wave morphing synthesizer
- Single/multi double/Keysplit sound options
- POLYTOUCH™ polyphonic aftertouch, on/off note velocity keyboard with 73
full-size keys
- MPE (MIDI Polyphonic Expression) compatibility
- Multifunctional ribbon controller (Modulation, Pitch bend, Theremin mode)
- Micro-tuning support via MIDI Tuning Standard files
- 1024 single program slots with category search
- 640 multiple program slots with 1280 program slots
- Two stereo audio outputs

- Type: Polyphonic wave morphing synthesizer
Sound engine: Wavescan
- Analog/digital: digital
- Number of keys: 73
- Keys: ASM POLYTOUCH™ polyphonic aftertouch keyboard, velocity sensitive on/off
- Other controllers: ribbon controller, pitch bend, modulation wheel
- Polyphony: 16 voices (Full/Layer/Split)
- Number of presets: 1024 single programs, 1280 programs in multi (upper/
- Number of Multis: 640 programs
- Oscillators: 3 x Wavescan oscillators (219 waveforms), 4 x Mutator wave shapers (8 types), noise (7 types)
- Mutators: 8 types (FM-Lin, WaveStack, PW-Orig, PW-Squeeze, PW-ASM, Harmonic Sweep, Hard
- Sync, PhazDiff)
- Noise: 7 types (white, pink, brown, red, blue, purple, grey)
- LFO: 5 per voice (Sine, Triangle, Saw Up, Saw Down, Square, Pulse27%, Pulse13%, S&H, Noise,
- Random, Step), Tempo sync, Semitone Lock
- Envelopes: 5 per voice, Tempo sync, variable trigger sources
- Filter types: 1 multi-mode filter (16 types) and 1 variable LP-BP/Notch-HP filter, serial or parallel routing
parallel routing
- Filters: Filter 1 (LP Ldr12, LP Ldr24, LP Fat12, LP Fat24, LP Gate, LP MS20, HP MS20, LP 3-Ler,
BP 3-Ler, HP 3-Ler, LP Stn12, BP Stn12, HP Stn12, LP 1 Pole, LP 8 Pole, Vowel), Filter 2 (LPBP-HP, LP-Notch-HP)
- Effects: 9 insert effects, 5 delays, 4 reverbs
- Effect types: Chorus, Flanger, Rotary, Phaser, Lo-Fi, Tremolo, EQ, Compressor, Distortion,
Delay, Reverb
- Arpeggiator: 8 types (High, Low, High and Low, High/Low, Order, Random, Chord, Phrase)
- Others: Mod Matrix (32 slots), Macro Controllers (8), Favorites (32), Randomizer (Patch and Module),
- MPE compatibility, Warm Mode, Microtuning
- Audio Outputs: 4 x 1/4" balanced (L/Mono upper, R upper, L lower, R lower)
- Headphones: 1 x 1/4", 1 x 1/8", separate volume control
- USB: 1 x Type B
- MIDI I/O: In/Out/Thru
- Pedal inputs: 2 x 1/4" (expression, sustain)
- Other I/O: 2 x 1/8" inputs (Mod 1, Mod2), 5 x 1/8" outputs (CV, Gate, Mod1, Mod2, Clock)
- Power supply: 12V DC
- H x W x D: 9.2 x 112.9 x 34.6 cm
- Weight: 13.3 kg
