500 series components
The Seventeen 500 isn't just another '76 compressor. It's the Black Lion 500 series version of a classic '76 compressor, redesigned and improved.
Seventeen 500 highlights
- Clear, incisive sound in light compression, and warm, colorful vintage character when pushed.
- Extended tonal range thanks to a redesigned input circuit and custom Black Lion output transformer.
- Exclusive power supply decoupling for extremely low background noise.
- Use of high-end Nichicon signal capacitors to reduce noise.
- Frequency-adjustable sidechain for greater flexibility.
- Wet/Dry button for parallel compression, a feature not found on vintage compressors.
- Stereo link for convenient duo use.
Seventeen 500 Key Features
Innovative input circuit
The Seventeen 500 stands out for its improved input circuit, based on an integrated circuit. This modern design delivers a clear, incisive sound when lightly compressed, while offering a colorful vintage character when pushed to the limit.
Custom Output Transformer
The Seventeen 500 incorporates a custom Black Lion output transformer that delivers deep, rich bass, subtly balanced by brilliant highs, offering a much wider tonal range than conventional compressors.
Exclusive Power Decoupling
Exclusive power supply decoupling guarantees extremely low background noise, delivering outstanding sonic performance even in the most demanding environments.
Sidechain and Wet/Dry Mixing
The Seventeen 500 features a frequency-adjustable sidechain, giving you total control over dynamics. The Wet/Dry button also enables parallel compression, an option not found on vintage compressors.
Stereo operation and "All-Buttons In" mode
The Seventeen 500 features a stereo link for convenient duo use. The "all-buttons in" mode provides explosive ambience or ultra-present vocals, ideal for creative applications.
Intuitive Ratio Activation
Activation of the various ratios is now more intuitive, simplifying their simultaneous use for optimum control, where conventional models were sometimes more complex to handle.
Lire la suite
Technical sheet
- Type
- 500 format FET compressor
- High-pass filter (HPF) on side chain
- Off, 100 Hz, 200 Hz
- Power supply
- ± 16 V
- Format
- Compact 500
- Circuit
- Optimized with output transformer
- Features
- Variable high-pass filter in the side chain
- Parallel compression in the signal path
- Ratio switching: push-buttons for classic ratio selection
- Available ratios: 4:1, 8:1, 12:1, 20:1, and "All-buttons in".
- Controls
- Attack adjustable from 20 µS to 800 µS
- Release adjustable from 1200 mS to 50 mS
- Comp Mix for parallel mix control
- Integrated Vu-meter
- Stereo connection: Link for stereo coupling of 2 units
- Input/output
- 1 stereo link (RCA, unbalanced)
- Frequency response
- 20 Hz to 22 kHz (±1 dB)
- Signal-to-noise ratio
- > 78 dB
- Total harmonic distortion + noise (THD+N)
- 0,08%
- Supply voltage
- 115/230 V AC, switchable at rear
- Dimensions
- 149 x 77 x 134 mm
- Weight
- 1.47 kg
