Boss BR800

Name: BR800
Brand: Boss
SKU: 12961
Availability: OutOfStock
Rating: 3 (1 reviews)

Read reviews (1)
Related accessories
Similar products

398,00 €

Free delivery
Low prices guaranteed
Satisfied or refunded
3-Years warranty
Ref : 12961

Not available at this moment

Stock in store

Not available in store

INFORM ME OF ITS ENTRY IN STOCK

I want to be notified by email

The brand Boss

Learn more about the Boss brand and discover the entire catalog.

Discover

The largest network of stores in France

Find all the information on our superstores and our specialized boutiques.

find out more

Contact an expert

Our musician and enthusiast tele-consultants are here to answer all your questions.

+33 181 930 900 email

Multi tracks recorder

Whether you’re creating intricate, multi-layered songs or point-and-capture field recordings, the BOSS BR-800 makes the recording process fast and easy. Beginners will love the new EZ Recording mode that interactively guides you through the recording process. Other helpful features include the convenient Retry function, which recues automatically to fix mistakes, and Song Sketch recording for instant, one-touch capture. There’s also a built-in stereo condenser microphone plus a DR-880-quality rhythm generator for adding drum and percussion tracks to your songs.

Enhance your recordings with the powerful BOSS effects onboard the BR-800.

Technical sheet

Number of Tracks:
Track: 8
Simultaneously recording track: 4
V-Track: 64 (8 V-Tracks per each Track)
Sample Rate: 44.1 kHz
Frequency Response: 20 Hz to 20 kHz (+1/-3 dB)
AD Conversion:
24-bit
24-bit + AF method (GUITAR/BASS input)
*AF (Adaptive Focus) method is a proprietary method from Roland that vastly improves the signal-to-noise (S/N) ratio of the A/D and D/A converters.
DA Conversion: 24-bit
Compatible Card Capacity:
SD Card: 1 GB to 2 GB
SDHC Card: 4 GB to 32 GB
Data Type
HiFi (MT2) Roland/BOSS original format
16 bit linear stereo WAV format(*)
*SONG SKETCH only
Recording Time
(for multi-track recording)
*Conversion in one track
1 GB: 8 hours 40 minutes
2 GB: 17 hours
4 GB: 34 hours
8 GB: 68 hours
16 GB: 136 hours
32 GB: 272 hours
* The above-listed recording times are approximate. Times may be slightly shorter depending on the number of songs that were created.
* The above number is the total for all the tracks that are used. If each of the eight tracks contain an equal amount of data, the length of the resulting song will be approximately 1/8 of the above.
Recording Time:
(for SONG SKETCH)
*Stereo recording
1 GB: 90 minutes
2 GB: 3 hours
4 GB: 6 hours
8 GB: 12 hours
16 GB: 24 hours
32 GB: 48 hours
Nominal Input Level:
GUITAR/BASS jack: -10 dBu
INPUT 1 to 4 jacks: -50 to -20 dBu (XLR type), -26 to +4 dBu (1/4" TRS phone type)
LINE IN jack: -10 dBu
Input Impedance:
GUITAR/BASS jack: 1 M ohm
INPUT 1 to 4 jacks: 3k ohms (XLR type), 47 k ohms (1/4" TRS phone type)
LINE IN jack: 10 k ohms
Nominal Output Level: LINE OUT jacks: -10 dBu
Output Impedance: LINE OUT jacks: 1 k ohm
Recommended Load Impedance:
LINE OUT jacks: 20 k ohms or greater
PHONES jack: 32 to 100 ohms
Residual Noise Level: LINE OUT jacks:-85 dBu or less (IHF-A Typ.)
Display: 128 x 64 dots (Backlit LCD)
Connectors
GUITAR/BASS jack (1/4" phone type), INPUT 1 to 4 jacks (XLR type / 1/4" TRS phone type), LINE IN jack (Stereo miniature phone type), FOOT SW/EXP PEDAL (1/4" TRS phone type), LINE OUT jacks (RCA phono type), PHONES jack (Stereo 1/4" phone type), USB connector, DC IN jack
USB Function: Audio Input/Output, MIDI Input/Output, File Transfer, BUS Power operation
Power Supply:
DC 9V: AC Adaptor
Size AA Dry battery x 6 (alkaline batteries recommended)
USB Bus Power
Current Draw:
280 mA (DC IN)
480 mA (USB Bus Power)
Battery Life for Continuous Use: Approximately 5.5 hours
(Alkaline dry batteries, with continuous playback of 8 tracks, phantom power off)
* May vary according to usage conditions, phantom power used, batteries used, and type of SD card used.
Accessories
SD Card, AC Adaptor, USB Cable, Owner's Manual
Options:
Footswitch: FS-5U, Pedal Switch: DP-2 (Roland), Expression Pedal: EV-5 (Roland), FV-500L/FV-500H
Size and Weight:
Width: 289 mm - 11-7/16 inches
Depth: 184 mm - 7-1/4 inches
Height: 58 mm - 2-5/16 inches
Weight: 890 g

More specifications

Fewer specifications
