Active full-range speaker
The new LINEAR 5 MKII series is a completely revised version of the successful LINEAR 5 series. Made in Germany and incorporating the latest technological innovations, it is aimed at professional groups and service providers looking for sophisticated, versatile, flexible and economical tools for their day-to-day activities.
One of the major evolutions of the MKII version is the addition of a powerful DSP, remotely controllable via dedicated software and an Ethernet connection. LINEAR 5 MKII loudspeakers can thus be integrated and managed over a network. HK has also provided for the possibility of including loudspeakers with their own DSP, offering even greater flexibility in professional installations.
A high-performance active point-source loudspeaker
Designed for broadcasting over medium distances, the LINEAR 5 MKII is a robust and reliable active point-of-source loudspeaker, suitable for live concerts, events and professional performances.
Clear, balanced reproduction
The midrange register is provided by 3 x 8" drivers, coupled to a 1" compression driver. compression driver, guaranteeing precise reproduction of high frequencies, for a powerful, balanced sound.
Innovative MCT waveguide
Equipped with an MCT (multi-cell transformer) waveguide, the LINEAR 5 MKII offers an asymmetrical dispersion of 60° x +5/-25°, enabling sound coverage to be adapted to different stage and audience configurations.
LINEAR 5 MKII highlights
-
Advanced DSP technology
- Powerful integrated DSP, remotely controllable via software
- Ethernet connection for network management
- Compatible with speakers without native DSP
-
Design and manufacture
- Made in Germany from premium components
- Robustness and reliability for intensive use
-
Sound performance
- 3 x 8" midrange drivers
- 1" compression driver for high frequencies
- MCT waveguide for 60° x +5/-25° dispersion
-
Applications
- Active point-of-source loudspeaker ideal for medium-distance broadcasting
- Suitable for live bands, DJs, event providers and fixed installations
Lire la suite
Technical sheet
- PA power speaker 601 to 1000 watts RMS
- Type of PA speaker Stage & FOH monitor
- Type
- Active loudspeaker
- Category
- Sound
- Amplification
- Active (amplified)
- Application
- Front panel
- Auto-standby
- No
- Bluetooth
- No
- Connection
- Link XLR
- RJ45
- XLR
- Inputs
- XLR/jack combo
- RJ45
- Outputs
- Link XLR
- XLR DSP
- Controls
- Volume
- Input gain
- Delay
- Equalization
- DSP
- Yes
- Number of channels
- 2 channels
- Speakers
- 3 x 8"
- 1" tweeter
- Crossover frequency
- 1.7 kHz
- Frequency response
- 105 Hz - 17 kHz
- Power
- 600 W RMS
- 1,200 W peak
- Sound pressure level
- SPL max: 133 dB
- Peak SPL: 138 dB
- Dispersion
- Horizontal: 60
- Vertical: 5.25
- Structure
- Birch multi-ply
- Finish
- Black lacquer
- Dimensions
- 440 x 680 x 460 mm
- Weight
- 25 kg
- Mounting
- Free-standing or overhead
- Baseplate width
- 35 mm
- Transport
- 2 handles
- Type of protection
- Power limiter
- Insert type
- M8
