Presonus StudioLive-16R

  • Read reviews (0)
  • Related accessories
  • Similar products
  • Presonus Studiolive-16r - Digital mixing desk - Main picture
  • Presonus Studiolive-16r - Digital mixing desk - Variation 1
  • Presonus Studiolive-16r - Digital mixing desk - Variation 2
  • Presonus Studiolive-16r - Digital mixing desk - Variation 3
  • Presonus Studiolive-16r - Digital mixing desk - Variation 4
1199,00 €
  • Free delivery
  • Low prices guaranteed
  • Satisfied or refunded
  • 3-years warranty
  • Ref : 77293
In stock
shipped under 8/10 days
Stock in store
Not available in store
Other version(s) or associated product(s)

The brand Presonus

Learn more about the Presonus brand and discover the entire catalog.

The largest network of stores in France

Find all the information on our superstores and our specialized boutiques.

Contact an expert

Our musician and enthusiast tele-consultants are here to answer all your questions.

Digital mixing desk

The Presonus StudioLive 16R Series III rack mixer is a perfect partner for your StudioLive Series III console/recorder, serving as either a simple stage box or a combination stage box and monitor mixer. Since Series III rack mixers and consoles can network using AVB, you can connect your StudioLive 16R to a Series III front-of-house console with one lightweight CAT5e or CAT6 Ethernet cable, eliminating the need for a heavy, expensive copper snake—and the signal degradation that goes with long analog cable runs. You can even remote control the StudioLive 16R’s preamps and phantom power from your networked Series III console. In stage box + monitor mixer mode, the StudioLive 16R not only serves as an excellent networked stage box, it is a full blown monitor mixer with far more processing and mixing power than any mixer in its class—all packed into just one rackspace. (1U).
Lire la suite

Technical sheet

  • Number of channel mixing desk 10 to 22 channels
  • Local Inputs and Outputs
  • 18 total inputs
  • 16 mic/line channel inputs + 2 RCA inputs
  • 6 ¼-inch TRS FlexMix outputs
  • 2 XLR (L/R) Main outputs
  • Stereo headphone output
  • Channels and Buses
  • 16 input channels
  • 1 stereo digital return (SD Card, AVB, or USB)
  • 10 buses:
  • 6 FlexMixes (can be designated as aux, subgroup, or matrix mixes)
  • 2 internal effects sends
  • Stereo main bus
  • 6 Filter DCAs for easily and flexibly controlling groups of channels
  • Networking Connections
  • 1 Ethernet control network port
  • Dynamic, Self Assigned, and Manual IP address modes
  • 1 Locking XLR Ethernet AVB audio network port
  • Recording
  • Onboard stereo SD recorder
  • 18x18 USB recording interface
  • 32x32 AVB recording interface
  • Signal Processing
  • Intuitive Fat Channel signal processing on every channel with:
  • A/B settings comparison
  • Highpass filter and polarity reverse
  • Gate/expander with sidechain
  • Compressor with sidechain
  • 4-band parametric EQ on inputs
  • 6-band parametric EQ on outputs
  • Limiter
  • Delay on every input
  • Delay on every output
  • Professionally programmed library of presets
  • Vintage EQ and compressor models available on every input
  • Passive EQ
  • Vintage EQ
  • Tube compressor
  • FET compressor
  • 8 31-band graphic EQs
  • 2 internal effects buses: combination of reverbs and delays with modern and vintage options
  • Built-in real-time analyzer
  • Scenes and Presets
  • Create, save, and edit up to 100 scenes
  • Scene management with:
  • Scene Safe—prevents a scene change from affecting designated “safe” channels
  • Create, save, and edit channel settings and copy/paste between channels
  • Advanced channel preset options can save and recall:
  • Channel type and name
  • Input settings (preamp, +48V phantom power, polarity, pan)
  • Fat Channel A & B settings
  • Bus assignments
  • Aux and effects send levels and pan
  • Select button color
  • 8 Quick Scenes
  • 8 Mute groups
  • Digital
  • Studio-quality converters with 115 dB dynamic range
  • 48 kHz operation with 24-bit resolution (44.1 kHz option coming soon)
  • Actively Integrated Software
  • UC Surface touch control software for Mac®, Windows®, iPad®, and Android ™
  • Studio One® Artist digital audio workstation software for Mac and Windows
  • Capture™ multitrack recording software for Mac and Windows
  • QMix®-UC aux-control software for iOS® and Android™ available free from Apple App Store and Google Play
More specifications
