Technical sheet
- Type
- Dynamic (voice coil)
- Directivity
- Unidirectional (Cardioid)
- Frequency response
- 50 Hz to 16,000 Hz
- Maximum SPL
- 128 dB SPL
- Sensitivity
- -33 dBFS/Pa at 1 kHz (1 Pa = 94 dB SPL)
- Adjustable gain range
- 0 to +36 dB (At minimum gain)
- Induced Digital Noise
- 20 Hz to 20 kHz, A-weighted
- Supported types (Input)
- XLR, 6.35 mm TS, 6.35 mm TRS
- Input impedance (XLR)
- 5.8 kΩ
- Input impedance (jack)
- 1 MΩ
- Adjustable gain range (XLR)
- 0 to +60 dB
- Adjustable gain range (jack)
- 0 to +40 dB
- Maximum input level (XLR)
- -118 dBFS (with AutoLevel mode and real-time Denoiser enabled)
- Maximum input level (Jack)
- -97 dBFS (@10 dB gain)
- Digital induced noise (Input)
- 20 Hz to 20 kHz, A-weighted
- Phantom power supply
- Yes, +48 VDC
- Additional functions
- AutoLevel mode with SmartGate, Digital Popper Stopper, Realtime Denoiser, Tone Slider, Reverb, Compressor, Limiter, Low Cut Filter
- On-board DSP
- Yes
- USB configuration required
- USB Audio Class 2 (UAC2), powered via USB bus (USB 2.0 or higher)
- A/D converter
- 24-bit, 48 kHz (supports 16-bit, 44.1 kHz for iOS)
- Headphone output
- 3.5 mm (1/8")
- Connector
- USB-C port
- Mounting type
- 5/8"-27" thread
- Net weight
- 567 g
- Microphone dimensions
- Length: 169.5 mm, Diameter: 90 mm (including yoke and clamping screws)
- Microphone dimensions in yoke
- H 164 mm x W 207 mm x D 90 mm
- Assembly
- Microphone and yoke assembled at 90° to each other, measured from the table to the top of the microphone
- Cable supplied
- 1 x 3 m USB-C to USB-C cable
- Compatible applications
- MOTIV Mix Desktop App, MOTIV Audio iOS & Android Apps
- Minimum System Requirements (Windows)
- System: Windows 10 or later, Memory: Minimum 8 GB RAM, Disk space: 20% or more free space
- Minimum System Requirements (MacOS)
- System: MacOS 12 or later, Memory: Minimum 8 GB RAM, Disk space: 20% or more available space
- Minimum System Requirements (iOS)
- System: iOS 16 or later, Note: Devices compatible only with USB-C
- Minimum System Requirements (Android)
- System: Android 12 or later, Certification: MFi certified (Made for iPhone/iPad)
