Yamaha MODX8+
- Read reviews (2)
- Related accessories
- Similar products
The brand Yamaha
Learn more about the Yamaha brand and discover the entire catalog.
The largest network of stores in France
Find all the information on our superstores and our specialized boutiques.
Contact an expert
Our musician and enthusiast tele-consultants are here to answer all your questions.
Workstation
Lire la suite
Technical sheet
- Number of keys 88 keys
- Touch Heavy touch
- 88 keys, weighted GHS keyboard, initial touch
- Sound Generator: Motion Control Synthesis
- AWM2 :
- up to 8 elements per part
- 128 voices of polyphony
- 5.67 GB Waveform-ROM
- 1.75 GB Flash-RAM
- FM-X :
- up to 8 operators
- 88 Algorithms
- 128 polyphony voices
- Built-in effects, Part-EQ, Master-EQ
- 2,227 Preset Performances (up to 16 parts per Performance for Splits, Layers, MIDI-Multimode)
- Pitch and modulation wheel, Super Knob, four sliders, four buttons
- 7" Wide-VGA touchscreen
- Stereo Line Out: 6.3mm x 2 mono phone jack
- Stereo Line In: 2 x 6.3mm mono phone jack
- Stereo phone output: 6.3 mm stereo phone jack
- MIDI [IN]/[OUT]
- USB [TO DEVICE] for connecting USB memory sticks.
- USB [TO HOST] for connection to PCs, USB audio interface function (two stereo channels from PC to MODX+, five stereo channels from MODX+ to PC) and DAW remote control (for Cubase, Logic Pro, Ableton Live, Pro Tools).
- Two connectors for foot switches (Sustain and Assignable)
- Two connectors for foot switches
- Dimensions (W x D x H): 1333 mm × 404 mm × 160 mm
- Weight: 13.8 kg
- Accessories included
- User's manual
- Power adapter
- License and download code for Steinberg Cubase AI
- Optional accessories
- Foot pedals and controllers (FC3A, FC4A, FC5, FC7)
