Antelope audio

Discrete 8 premium FX
Thunderbold audio interface

(1 avis client)

1498.00 €
+
-
ON ORDER - contact us
INFORM ME OF ITS ENTRY IN STOCK
BIEN REÇU, MERCI!
OK
Please enter a valid email address
  • Need help +33 1 81 930 900

  • Fast delivery

  • Guarantee : 3-years warranty

    days refund guarantee : within 30 days

Share

Description

Antelope Audio’s Discrete 8 Microphone Preamp Interface brings a new level of sound quality and power to home studios and mobile recordists. It comes with 8 console grade 6-transistor discrete preamps, 121 db dynamic range conversion and rock solid clocking.

Discrete 8 features all of the Antelope Audio premier real-time FPGA FX, including authentic models of iconic gear from BAE, Lang, Gyraf Audio and many more.

The Antelope AFX platform is a rapidly expanding hardware modeling engine. Discrete 8 includes Accusonic 3D microphone and preamp models, guitar amps, transformer and tube FX, and a huge selection of classic vintage gear, which are now accessible in the DAW via the new ConnectAFX Plugin.

Characteristics

Ref : 77105
- Dsp : yes
ANALOG
Analog Inputs
6 x Mic / Line Inputs
2 x Mic / Line / Hi-Z Inputs

Analog Outputs
1 x Monitor Out on TRS 1/4 Jacks, +20 dBu max
1 x ReAmp Out on TRS 1/4 Jacks
1 x Line Outs on DB25, +20 dBu max
2 x Stereo Headphone Outputs

Mic Preamp
EIN: -128 dBu (A-weighted)
Dynamic Range: -121 dB (A-weighted)
THD: -106 dB
Max input: +18 dBu
Gain Range: 65 dB

D/A Monitor Converter
Dynamic Range: 124 dB
THD + N: -101 dB

A/D Converter
Dynamic Range: 121 dB
THD + N: -112 dB

D/A Converters(Line Out)
Dynamic Range: 121dB
THD + N: – 100dB

DIGITAL
Digital Inputs
2 x ADAT (up to 16CH)
1 x S/PDIF

Digital Outputs
2 x ADAT (up to 16CH)
1 x S/PDIF

USB I/O
USB 2.0 Hi-Speed;

Data stream up to 480 Mbits/192kHz, 24 channels I/O, Type B

Thunderbolt™ I/O
1 x Thunderbolt, 32 channels I/O

CLOCKING
Word Clock Input
1 x Input @ 75 Ohms 3Vpp on BNC 32 – 192kHz

Word Clock Outputs
3 x Outputs @ 75 Ohms 3Vpp on BNC 32 – 192kHz

Clocking System
4th Generation Acoustically Focused Clocking
64-bit DDS

Sample Rates (kHz)
32, 44.1, 48, 88.2, 96, 176.4, 192

Other
Operating Temperature
0-50°C, 32-122°F

Weight (Approx)
3.0 kg/ 6.61 lbs

Dimensions (Approx)
Width: 483 mm / 19”
Height: 44 mm / 1.7”
Depth: 220 mm /8.6”

Power Consumption
20 Watts
