Lyre
DMX Channels:8, 10, or 14DMX Connectors: 3-pin XLRMax Unobstructed Distance:600 ft (183 m)Pan and Tilt:540°/240°Pan and Tilt Ranges:180°, 360°, 540° pan/90°, 180°, 240° tiltColors:8 + open, split colors, continuous scroll at variable speedsGobos:7 + open (6 metal + 1 glass), rotating, interchangeable, slot-n-lock, continuous scroll at variable speedsLight Source:1 LED (cool white) 70 W, (3.3 A), 50,000 hours life expectancyStrobe Rate:0 to 23 HzRecharge Time:6.75 hoursOperating Frequency:2.412 to 2.484 GHzIlluminance:
16,932 lux @ 2 m
9,424lux @ 2 mInput Voltage:100 to 240 VAC, 50/60 Hz (auto-ranging)Power and Current:
110 W, 0.9 A @ 120 V, 60 Hz
107 W, 0.5 A @ 230 V, 50 HzGobo Size:28 mm outside, 23.8 mm image, 1.1 mm max thicknessWeight:22 lb (9.9 kg)Size:9.7 x 10.2 x 11.1 in (246 x 258 x 283 mm)Approvals:CE, UKCA , RoHS , FCCPrism: 3-facet round staticZoom Range (manual): 13° to 19 °Run Time (adjustable): 4, 6, or 8 hrsRecharge Time: 6.75 hoursColor Temperature: 15,000 KBracket Mounting Hole: M12Optional Controllers: RFC, RFC-XL
WHAT'S INCLUDED
Intimidator Free Spot 60 ILSPower cordOmega bracketQuick Reference Guide
16,932 lux @ 2 m
9,424lux @ 2 mInput Voltage:100 to 240 VAC, 50/60 Hz (auto-ranging)Power and Current:
110 W, 0.9 A @ 120 V, 60 Hz
107 W, 0.5 A @ 230 V, 50 HzGobo Size:28 mm outside, 23.8 mm image, 1.1 mm max thicknessWeight:22 lb (9.9 kg)Size:9.7 x 10.2 x 11.1 in (246 x 258 x 283 mm)Approvals:CE, UKCA , RoHS , FCCPrism: 3-facet round staticZoom Range (manual): 13° to 19 °Run Time (adjustable): 4, 6, or 8 hrsRecharge Time: 6.75 hoursColor Temperature: 15,000 KBracket Mounting Hole: M12Optional Controllers: RFC, RFC-XL
WHAT'S INCLUDED
Intimidator Free Spot 60 ILSPower cordOmega bracketQuick Reference Guide
Lire la suite
Technical sheet
- DMX compatible Yes
- DMX Channels: 8, 10, or 14
- DMX Connectors: 3-pin XLR
- Max Unobstructed Distance: 600 ft (183 m)
- Pan and Tilt: 540°/240°
- Pan and Tilt Ranges: 180°, 360°, 540° pan / 90°, 180°, 240° tilt
- Colors: 8 + open, split colors, continuous scroll at variable speeds
- Gobos: 7 + open (6 metal + 1 glass), rotating, interchangeable, slot-n-lock, continuous scroll at variable speeds
- Light Source: 1 LED (cool white) 70 W, (3.3 A), 50,000 hours life expectancy
- Strobe Rate: 0 to 23 Hz
- Recharge Time: 6.75 hours
- Operating Frequency: 2.412 to 2.484 GHz
- Illuminance:
- 16,932 lux @ 2 m
- 9,424 lux @ 2 m
- Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
- Power and Current:
- 110 W, 0.9 A @ 120 V, 60 Hz
- 107 W, 0.5 A @ 230 V, 50 Hz
- Gobo Size: 28 mm outside, 23.8 mm image, 1.1 mm max thickness
- Weight: 22 lb (9.9 kg)
- Size: 9.7 x 10.2 x 11.1 in (246 x 258 x 283 mm)
- Approvals: CE, UKCA, RoHS, FCC
- Prism: 3-facet round static
- Zoom Range (manual): 13° to 19 °
- Run Time (adjustable): 4, 6, or 8 hrs
- Recharge Time: 6.75 hours
- Color Temperature: 15,000 K
- Bracket Mounting Hole: M12
- Optional Controllers: RFC, RFC-XL
- WHAT'S INCLUDED:
- Intimidator Free Spot 60 ILS
- Power cord
- Omega bracket
- Quick Reference Guide
