Electro harmonix Pitch Fork +
- Read reviews (0)
- Related accessories
- Similar products
VIDEO
VIDEO
- Free delivery
- Low prices guaranteed
- Satisfied or refunded
- 3-years warranty
- Ref : 93956
Not available at this moment
contact us
Stock in store
Not available in store
INFORM ME OF ITS ENTRY IN STOCK
I want to be notified by email
Go
The brand Electro harmonix
Learn more about the Electro harmonix brand and discover the entire catalog.
Guitar and bass effects shopping guide
How to find the processor(s) that correspond to your needs and expectations amongst the hundreds of references currently available?
Contact an expert
Our musician and enthusiast tele-consultants are here to answer all your questions.
Harmonizer effect pedal
The EHX Pitch Fork + Polyphonic Pitch Shifter compacte effect pedal features two independent pitch shifting engines with full control over each. Both will transpose your pitch up or down over a +/- three octave range and detune +/-99 cents. With rock solid tracking, an organic, musical tone and extensive control, it’s your ultimate harmonizer.
Lire la suite
Technical sheet
- EHX Pitch Fork + Polyphonic Pitch Shifter
- SKU EHXPIT
- Programmable compact effect pedal for electric guitar & bass
- 2021
- Digital circuit
- 2x independent engines with full control over each
- Transpose your pitch up8down over a +/- 3x octave range and detune +/-99 cents
- 8x modes including X-MOD which features cross modulation that creates FM and ring mod type effects and LATCH which provides enhanced Latch and Momentary functionality
- Dedicated volume controls for both Shift voices and the Dry signal
- 10x unique factory presets plus the ability to easily create/save/recall 100x programs
- Bypass footswitch toggles between effect on and buffered bypass (in latch mode switches between effect and bypass mode)
- In Momentary mode the effect is on when the FS is held down and the pedal enters bypass when it’s released
- Programmable user footswitch that can be assigned to a variety of functions such as muting either Shift voice or jumping to a preset program (dedicated LED)
- EXP input for EXP or CV control over a broad selection of parameters in three sub-menus (Frequency, Glissando and Volume)
- EXT input for connecting an external foot controller like EHX’s Triple Foot Controller which enables players to change modes, enter/exit sub-menus and load presets
- 2x outputs, Main and Aux, with multiple routing options
- Other controls : see pictures
- Connections : see pictures
- True bypass
- Powered via included 9VDC power supply (no battery operation)
- Current draw 200 mA
- 102 x 121 x 57 mm
- Manual : https://docs.google.com/gview?url=https://hrgrtw7vqvg2.cdn.shift8web.ca/wp-content/uploads/2021/01/pitch-fork-plus-manual.pdf&embedded=true
More specifications
Fewer specifications
