The brand Hk audio
Learn more about the Hk audio brand and discover the entire catalog.
How to choose your PR System Buying guide
Power, loudspeaker size, price, efficiency, dimensions, passive or active version... Choosing a loudspeaker is no easy task! In this guide, you will find several ways to help you make your choice acco
Contact an expert
Our musician and enthusiast tele-consultants are here to answer all your questions.
Active full-range speaker
LINEAR 7 is the latest and most advanced range in the LINEAR series.
It is aimed in particular at professional bands, DJs and service providers. What sets LINEAR 7 apart, and makes it the tool of choice for use in "live" conditions, is its advanced DSP technology controlled via Ethernet. This technology makes it possible to control other LINEAR series loudspeakers using the DSP output integrated into LINEAR 7 models. What's more, LINEAR 7 also offers user-configurable cardioid functions, and features the Milan protocol, the new and future digital audio network standard for audio streaming.
- Ultra-precise coverage of the frequency spectrum thanks to minimized distortion and optimized directivity.
- Sophisticated DSP platform with integrated, fully parametric 10-band equalizer, delay and limiter for individual configuration without compromise.
- Network technology to control the DSP of each LINEAR 7 loudspeaker from a single point via a dedicated Windows and Mac OS compatible application (app for iPad planned).
- Additional DSP output for integrating a non-compatible powered loudspeaker (e.g. LINEAR SUB active subwoofers) into the network and controlling it remotely with all LINEAR 7 DSP parameters.
- Direct access to presets for monitoring or system use, even in off-network configuration.
- High-resolution 96 kHz converters, FIR filter, low latency.
- Ergonomic mounting and attachment options.
It is aimed in particular at professional bands, DJs and service providers. What sets LINEAR 7 apart, and makes it the tool of choice for use in "live" conditions, is its advanced DSP technology controlled via Ethernet. This technology makes it possible to control other LINEAR series loudspeakers using the DSP output integrated into LINEAR 7 models. What's more, LINEAR 7 also offers user-configurable cardioid functions, and features the Milan protocol, the new and future digital audio network standard for audio streaming.
- Ultra-precise coverage of the frequency spectrum thanks to minimized distortion and optimized directivity.
- Sophisticated DSP platform with integrated, fully parametric 10-band equalizer, delay and limiter for individual configuration without compromise.
- Network technology to control the DSP of each LINEAR 7 loudspeaker from a single point via a dedicated Windows and Mac OS compatible application (app for iPad planned).
- Additional DSP output for integrating a non-compatible powered loudspeaker (e.g. LINEAR SUB active subwoofers) into the network and controlling it remotely with all LINEAR 7 DSP parameters.
- Direct access to presets for monitoring or system use, even in off-network configuration.
- High-resolution 96 kHz converters, FIR filter, low latency.
- Ergonomic mounting and attachment options.
Lire la suite
Technical sheet
- PA power speaker 1501 to 2000 watts RMS
- Type of PA speaker Stage & FOH monitor
- Amplification
- Active (amplified)
- Application
- Front of house, Stage monitor
- Bluetooth
- No
- Category
- Sound
- DSP
- Yes
- Speaker diameter
- 12"
- Dimensions (mm)
- 37 x 67 x 31 mm
- Horizontal dispersion
- 70°
- Vertical dispersion
- 50°
- Inputs
- XLR, powerCON, RJ45
- Finish
- Black lacquer
- Crossover frequency
- 1.6 kHz
- Base width
- 35 mm
- Mounting
- 35 mm stand
- Number of channels
- 2 lanes
- Pan cut
- Yes
- Weight
- 21 kg
- SPL Max / peak
- 131 dB
- Power (W)
- 2 000 W
- Peak power (W)
- 2 000 W
- Frequency response
- 67 Hz - 19 kHz
- SPL max
- 128 dB
- Outputs
- Link XLR, RJ45
- Loudspeaker structure
- Multiply birch - MDF
- Transport
- 2 handles
- Tweeter
- 1"
- Type
- Active speaker
- Enclosure protection type
- Power limiter
- Insert type
- M8
