Neve 33609N

  • Read reviews (0)
  • Related accessories
  • Similar products
  • Neve 33609n - Kompressor Limiter Gate - Main picture
  • Neve 33609n - Kompressor Limiter Gate - Variation 1
  • Neve 33609n - Kompressor Limiter Gate - Variation 2
3795,00 €
  • Free delivery
  • Low prices guaranteed
  • Satisfied or refunded
  • 3-years warranty
  • Ref : 72360
Not available at this moment
contact us
Stock in store
Not available in store
INFORM ME OF ITS ENTRY IN STOCK
I want to be notified by email
Go

The brand Neve

Learn more about the Neve brand and discover the entire catalog.

The largest network of stores in France

Find all the information on our superstores and our specialized boutiques.

Contact an expert

Our musician and enthusiast tele-consultants are here to answer all your questions.

Kompressor limiter gate

- Classic Stereo Compressor / Limiter designed to exacting 1970’s specifications
- Made using hand-wired Neve transformers in Burnley, England
- Classic 2254 feedback compression circuitry
- Brick Wall Limiting
- Transparent level control
- Perfect for mixing, broadcast, and mastering applications
- Hard Limit feature for digital recording
- Limit in/out Compress in/out
- Discrete output stage for slightly warmer sound
Lire la suite

Technical sheet

  • Frequency Response: +/- 0.5dB from 20Hz to 20kHz, measured at 0dBu relative to 1kHz
  • Distortion (80kHz bandwidth): 0.075% maximum (Bypass IN, Compress and Limit OUT, input level at +9dBu, 1kHz)0.2% maximum (Compress IN ratio 6:1, Gain make-up to MAX, Recovery: 800mS, Threshold -18dBu) 0.45% maximum (Limit IN, Compress OUT, Recovery 800mS, Input level +22dBu, Threshold -18dBu)
  • Noise: -75dBu with input terminated in 600 Ohms, Bypass IN, Compress and Limit OFF; -55dBu with compress IN and gain make-up at maximum (22Hz to 22kHz bandwidth
  • Limit Threshold: +4dBu to +15dBu
  • Limiter Ratio: With input level at 10dBu, then increased to +20dBu, the change in output level should be 0.1dB, +/-0.1dB
  • Limiter Attack Time: Slow 4mS, +/-1mS, fast 2mS, +/-1mS
  • Limiter Recovery Time: A1 (auto): 100mS/2seconds, A2 (auto): 50mS/5seconds
  • Compressor Ratio: 1.5:1, 2:1, 3:1, 4:1, 6:1
  • Compressor Attack Time: Slow 6mS +/-1mS, fast 3mS +/-1mS
  • Compressor Recovery Time: 100mS, 400mS, 800mS, 1.5S, and Auto 1 (100mS/2 sec) and Auto 2 (50mS/5 sec) settings.
  • Compressor Gain Make-up: Gain Make-up control provides 0dB to +20dB extra gain in 2dB steps when Compress switched IN.
  • Power Consumption: 5.3VA
  • Width: 482mm (19 inches)
  • Height: 88mm (3.46 inches)
  • Depth: 255mm (10.03 inches)
  • Weight: 5kg (11lbs)
More specifications
