Cartridge

With their iconic design inherited from the legendary Concorde MKI, Ortofon Concorde 5E and 5S cells embody the perfect balance between simplicity, reliability and audio performance.

Positioned just below the Concorde Music series, these two models offer an ideal gateway to quality vinyl listening, whether you're a curious audiophile or an everyday music lover.

Easy to use and extremely robust, the Concorde 5S is perfect for casual vinyl listening, without compromising on quality. Its spherical diamond provides stable, forgiving playback, even if your installation is not perfectly optimized.

Technical sheet

Hi-Fi Phono cell - Technical specifications
- High-fidelity moving-coil stereo cell
Output voltage
- 4 mV at 1000 Hz, 5 cm/sec
Pen type
- Spherical
Cantilever
- Aluminum
Pen tip radius
- R 18 µm
Coils
- 4 coils on split-pole supports (2+ and 2-)
Coil wire
- OFC - Oxygen-Free Copper
Channel balance
- 2 dB at 1 kHz
Channel separation
- 20 dB at 1 kHz
Frequency response
- 20 Hz - 20 kHz ±3 dB
Lateral dynamic compliance
- 20 ?m/mN
Recommended bearing force
- 1,8 g
Reading angle
- 20° (typical value)
Recommended load resistance
- 47 kΩ
Recommended load capacitance
- 200 - 500 pF
Color
- Black / Black (cell and pen)
Weight
- 18 g
