Active subwoofer
The SUB 8003-AS MK3 is a professional active subwoofer designed to meet the demands of high-end live shows, DJs, touring and fixed installations.
It features an 18" driver with a 4" voice coil, combined with a high-power digital amplifier and full DSP processing.
Thanks to its optimized design, it offers extended and precise bass reproduction, high maximum sound pressure, and flexibility of use (including cardioid mode, delay, system presets).
The sturdily-coated, multi-fold wooden case is ready for the road, with handles, mounting options and matching power cable.
It features an 18" driver with a 4" voice coil, combined with a high-power digital amplifier and full DSP processing.
Thanks to its optimized design, it offers extended and precise bass reproduction, high maximum sound pressure, and flexibility of use (including cardioid mode, delay, system presets).
The sturdily-coated, multi-fold wooden case is ready for the road, with handles, mounting options and matching power cable.
Lire la suite
Technical sheet
- PA power speaker 1001 to 1500 watts RMS
- Type of PA speaker Stage & FOH monitor
- Acoustic characteristics
- Frequency response: 35 Hz - 120 Hz
- Max. SPL (@ 1 m): 135 dB
- Driver: 1 × 18", 4" voice coil
- Load type: bass-reflex (ventilated load)
- Amplification / Electronics
- Peak power: 2,200 W
- Estimated RMS power: approx. 1,100 W
- Amplification: digital Class D
- Integrated DSP :
- Selectable presets
- Crossover / adjustable crossover frequency
- Cardioid mode
- Output delay adjustment
- Software limiter / thermal & RMS protection
- Cooling: convection (no fan)
- Connection & signal
- Inputs: XLR stereo (L/R) balanced/unbalanced
- Outputs: XLR stereo Link
- Input sensitivity: -2 dBu / +4 dBu (depending on setting)
- Power supply: professional PowerCON (IN/OUT) socket or equivalent
- Construction / Mechanics
- Cabinet: plywood (Baltic birch or equivalent)
- Finish: touring-resistant polyurethane coating
- Grille: steel with internal acoustic foam protection
- Handles: two side handles
- Base/insert: M20 for stand/pole mounting
- Stackable: designed for quick stacking and assembly
- Dimensions (H × W × D): ? 693 × 505 × 685 mm
- Weight: 37.6 kg
