Multieffect for electric guitar
The SOURCE AUDIO One Series Ultrawave Multiband Processor compact effect pedal embarks on a pioneering journey into the advanced potential of overdrive and tremolo, exploring a brave new universe of sounds yet unheard.
At the Ultrawave’s core is a dynamic and multi-dimensional approach known as multiband processing. This process splits the frequency spectrum of a guitar, bass, or synthesizer into multiple, discrete frequency bands and equips each band with its own array of adjustable parameters.
In the case of overdrive, the Ultrawave splits the incoming signal and provides separate drive and output level controls for each individual band. The result is a thick and rich distortion with loads of unique overtones and dynamic interplay. Split the signal into 1, 2, 3, 4, 8, or 10 frequency bands, and apply any of the band splitting options to an exciting collection of overdrive types, including Tube, Diode, Foldback (a method of distortion often heard in the world of synthesizers), Octave Up, Negative Flip Diode, and more. ?Plug in, turn up, and explore the wonders of multiband processing built on over a decade of refinement and experimentation.
At the Ultrawave’s core is a dynamic and multi-dimensional approach known as multiband processing. This process splits the frequency spectrum of a guitar, bass, or synthesizer into multiple, discrete frequency bands and equips each band with its own array of adjustable parameters.
In the case of overdrive, the Ultrawave splits the incoming signal and provides separate drive and output level controls for each individual band. The result is a thick and rich distortion with loads of unique overtones and dynamic interplay. Split the signal into 1, 2, 3, 4, 8, or 10 frequency bands, and apply any of the band splitting options to an exciting collection of overdrive types, including Tube, Diode, Foldback (a method of distortion often heard in the world of synthesizers), Octave Up, Negative Flip Diode, and more. ?Plug in, turn up, and explore the wonders of multiband processing built on over a decade of refinement and experimentation.
Lire la suite
Technical sheet
- SOURCE AUDIO One Series Ultrawave Multiband Processor
- SKU Source Audio SA251
- Electric guitar multiple effects
- Compact pedal
- 2021
- 37 Different Band Splitting Options including single, 2, 3, 4, 8, and 10 bands
- Each band splitting option includes several sub-sets with different band splitting frequency points
- 44 Different Distortion Types (distortion/overdrive/fuzz types including Tube, Diode, Foldback, Negative Flip Diode, Octave Up, and more)
- Dual Channel Compressor/Expander with Input Gain, Threshold, Ratio, Attack, Release, and Output Gain controls with a detailed graphic monitor
- Use the dual channel capabilities to isolate compression to specific frequencies
- Place the compressor/expander before or after the overdrive module
- Stereo Ins and Outs (create two entirely different presets and run them in series, parallel or run each to a separate output)
- Stereo options also apply to the Multiband Tremolo - use the Channel 1/Channel 2 Sync options or the Phase Offset control to create stereo ping-pong, tremolo effects
- Detailed LFO Controls (use the LFO module to control the Ultrawave's Tremolo, Morphing or Ring Mod features. Choose between a standard Sine Wave or use the Attack/Release controls to create highly customized LFO shapes)
- Sound Morphing : Change from one sound to another with an expression pedal, envelope follower or LFO
- 8 Band Graphic Equalizer
- Adjustable Noise Gate
- Assignable Knobs : Reassign all four of the Ultrawave's knobs to the parameters most useful for making quick, on-stage changes. Save a different set of knob assignments for every preset
- External Expression Pedal Control : Make simultaneous, on-the-fly changes of up to three parameters with an external expression pedal
- 6 Toggle Switch Accessible Presets : Quickly access up to 6 pedal presets with the Ultrawave's toggle switch
- Universal Bypass — Select either analog buffered or relay based True Bypass
- MIDI Capable — Connect the Ultrawave to the Source Audio Neuro Hub and access up to 128 presets with MIDI Program Change (PC) messages
- Control many of the pedal’s parameters with MIDI Continuous Controller (CC) messages or assign LFO modulation speed with MIDI Clock
- USB Port - Class compliant USB-MIDI allows the Ultrawave to work as a plug-and-play device with recording software running on Mac and Windows
- USB port offers connectivity to the Neuro Desktop Editor providing access to deep editing possibilities and pedal firmware updates
- Universal BypassTM – Select either analog buffered or relay based True Bypass
- Compact Design – The durable, anodized aluminum housing has a small footprint and sturdy hardware.
- 11.4 x 7 x 5.1cm (including knobs)
- Growing Library of Published Presets (Ultrawave Neuro Community)
- Manual : https://www.sourceaudio.net/uploads/1/1/5/1/115104065/uw_working_manual_v6.pdf
