Walrus audio Canvas Power HP Plus

  • Read reviews (0)
  • Similar products
  • Walrus Audio Canvas Power Hp Plus - Pedal power supply - Main picture
  • Walrus Audio Canvas Power Hp Plus - Pedal power supply - Variation 1
  • Walrus Audio Canvas Power Hp Plus - Pedal power supply - Variation 2
  • Walrus Audio Canvas Power Hp Plus - Pedal power supply - Variation 3
  • 418.00 €
  • Ref : 117887
399,00 €
  • Free delivery
  • Low prices guaranteed
  • Satisfied or refunded
  • 3-years warranty
Pre-order
contact us
Stock in store
Not available in store
INFORM ME OF ITS ENTRY IN STOCK
I want to be notified by email
Go

The brand Walrus audio

Learn more about the Walrus audio brand and discover the entire catalog.

The largest network of stores in France

Find all the information on our superstores and our specialized boutiques.

Contact an expert

Our musician and enthusiast tele-consultants are here to answer all your questions.

Pedal power supply

Canvas Power HP Plus is the perfect power solution for hybrid rigs running pedals, modelers, and/or multi-effect pedals, allowing you to power even the thirstiest of devices with two 3A (three-amp, or 3,000mA) outputs. HP Plus also includes seven isolated power outputs delivering up to 500mA of clean power at 9V, plus a 9/12/18V variable output. The 3A outputs can switch between 9V and 12V to power high-voltage pedals.

HP Plus brings simplicity and modularity to powering your modeler, multi-effect unit, or high-powered pedals. With two ports delivering up to 3A each and seven ports of silent, isolated, clean 9V power (up to 500mA each), HP Plus is perfect for hybrid rigs using pedals and modelers like the Quad Cortex, HX Series, and more. Canvas Power series is built using modern switch-mode supply architectures. This means each output is isolated, highly efficient, and heavily filtered, ensuring plenty of power with incredibly low noise.

The super-slim 1.2-inch design allows Canvas Power Supplies to fit under nearly any pedalboard, and the included universal mounting brackets mean you don’t have to worry about your power supply shifting when you’re hustling to your next gig.

The onboard LED power meter clearly shows how much power is being consumed, and each output has its own LED indicator to show when it's actively delivering power.
Lire la suite

Technical sheet

  • Two 3A outputs with selectable 9V or 12V
  • Seven isolated 9V outputs (up to 500mA each)
  • 9V/12V/18V variable output
  • Modern switch-mode architecture = clean, quiet power
  • Optional linkable configuration using a 24V power link
  • 1.2-inch design fits under nearly any pedalboard
  • Custom 2.1mm cables with short straight and right-angle plugs
  • LED output indicators + onboard power meter
  • 7 x 9VDC 500mA outputs
  • 1 x 9V, 12V or 18V variable output
  • 2 x 3A, 9V or 12V variable outputs
  • 1 x 5V 1.5A USB-C charging output
