Analog mixing desk

From the preamps, EQ and effects to the Hybrid Channel functions and iPod/iPhone connectivity—every aspect, every feature, every sound, establishes the MGP32X as a premium mixing console in a class of its own.

MGP Series mixing consoles offer two separate studio-grade effects processors for ultimate enhancement of your sound, with simple intuitive control.

The MGP Series utilizes a powerful, proprietary DSP to provide three essential features that are staples of both installed and live sound applications: a Priority Ducker, a Leveler and Stereo Image.

Technical sheet

Mixer connectivity USB
Number of channel mixing desk 24 channels and more
Number of channels 32 channels

Mixing capability
Mixing channels : 32 Line Inputs (24 mono and 4 stereo)
GROUP : 4 GROUP Buses + ST Bus
AUX : 6 AUX Sends + 2 FX Sends
MATRIX : 1 Matrix out
On-board processors : FX1:REV-X(8 PROGRAM, PARAMETER control)/ FX2:SPX(16 PROGRAM, PARAMETER control)
I/O
Mic inputs : MIC: 24 (INPUTS HPF: 100Hz 12dB/oct)
Phantom power : 48V phantom power per channel
Line inputs : LINE: 24 mono + 4 stereo, CH INSERT: 24 RETURN: 1 stereo
Digital I/O : USB Device, iPod / iPhone
General specifications
Total harmonic distortion : 0.02% (20Hz-20kHz@ +14dBu)
Frequency response : +0.5/-1.0dB 20Hz - 20kHz, refer to the nominal output level @1kHz
Hum & noise level
Equivalent input noise : -128 dBu Equivalent Input Noise
Residual output noise : -94 dBu Residual Output Noise
Crosstalk : -74dB @ 1kHz
Power requirements : 100-240V 50Hz/60Hz
Power consumption : 86W max
Dimensions
W : 1,027mm (40.4")
H : 169mm (6.7")
D : 565mm (22.2")
Net weight : 19kg (41.9lb)
