Zoom
Q4N
Portable recorder
Description
The ZOOM Q4N model is a standard of the portable recording of video & music; like its little brother the Zoom Q4, it features high quality sound and video fit for standard lighting.
A large range of settings will be at your command, allowing you to adapt to any situation.
A large range of settings will be at your command, allowing you to adapt to any situation.
Characteristics
Ref : 66021
SPECIFICATIONS
Recording media:
- SD/SDHC/SDXC cards
(Class 10 or higher, up to 128 GB)
- Image sensor: 1/3-inch 3-megapixel CMOS sensor
- Lens: Fixed focus (36 cm – ∞), F2.0,
- Focal distance approx. 16.6 mm (35 mm equivalent),
160? FOV
Video format:
- MPEG-4 AVC/H.264 (MOV)
Video resolutions:
- 3M HD (2304×1296) / 30 fps / 24 Mbps,
- HD1080p / 30 fps / 24 Mbps,
- HD1080p / 30 fps / 16 Mbps,
- HD720p / 60 fps / 15 Mbps,
- HD720p / 30 fps / 8 Mbps,
- WVGA 60 fps / 8 Mbps,
- WVGA 30 fps / 5 Mbps
Audio formats:
- WAV (16-/24-bit quantization, 44.1/48/96 kHz sampling frequency)
- AAC (64–320 kbps bit rate, 48 kHz sampling frequency)
Audio functions:
- Lo-Cut filter, Auto Gain
Image functions:
- Digital zoom (×0.75/×0.85/×1.00/×1.30/×1.50),
- Scene selection (Auto / Concert Lighting / Night / Concert-Low Light / Dance Club / Jazz Club / Concert Hall / Rehearsal-Studio / Garage / Outdoor / Sunset)
Self-timer:
- (Off/3sec/5sec/10sec)
- Display: 2.0" full-color touchscreen LCD
INPUT: MIC
- Type: 120° A/B and 120° X/Y stereo
- Maximum sound pressure input: 140 dB SPL
- Input gain: -30 to +44 dB
INPUT: EXTERNAL INPUT
- Input connector: Stereo mini jack
- Input gain: –∞ to +26 dB
- Input impedance: 2 k Ω or more
- Supports plug-in power
OUTPUTS
- Output connector: Combined line/headphones stereo mini jack
- HDMI connector: Micro Type D
- Built-in speaker: 400 mW 8 Ω mono speaker
USB: Operation as mass storage
- Class: USB 2.0 High Speed
USB: Operation as audio interface
- Class: USB 2.0 Full Speed
Specifications:
- 44.1 kHz sampling rate, 16-bit
- USB: Operation as webcam
Specifications:
- WVGA/720p video size,
- 48 kHz / 16-bit audio
- Note: Audio interface and mass storage operation with iPad is supported.
- Note: USB bus power supported
GENERAL
- Power supply:
- Lithium-ion battery: DC 4.2V maximum voltage,
- DC 3.7V nominal voltage, 1,050mAh capacity
AC adapter: ZOOM AD-17, sold separately: DC 5V/1A
Recharging times:
- Using USB: about 3 hours
- Using ZOOM AD-17: about 2 hours
- Battery operation time: About 3 hours or more
(when recording 720p/30 fps video with LCD closed)
External dimensions:
- Main unit (mic stored): 119 (length) × 51 (width) × 62 (height) mm
- Main unit (mic extended): 119 (length) × 39 (width) × 86 (height) mm
Weight:
- 6.0 oz / 178.6 grams with battery
- 5.5 oz / 155.9 grams without battery
SPECIFICATIONS
Recording media:
- SD/SDHC/SDXC cards
(Class 10 or higher, up to 128 GB)
- Image sensor: 1/3-inch 3-megapixel CMOS sensor
- Lens: Fixed focus (36 cm – ∞), F2.0,
- Focal distance approx. 16.6 mm (35 mm equivalent),
160? FOV
Video format:
- MPEG-4 AVC/H.264 (MOV)
Video resolutions:
- 3M HD (2304×1296) / 30 fps / 24 Mbps,
- HD1080p / 30 fps / 24 Mbps,
- HD1080p / 30 fps / 16 Mbps,
- HD720p / 60 fps / 15 Mbps,
- HD720p / 30 fps / 8 Mbps,
- WVGA 60 fps / 8 Mbps,
- WVGA 30 fps / 5 Mbps
Audio formats:
- WAV (16-/24-bit quantization, 44.1/48/96 kHz sampling frequency)
- AAC (64–320 kbps bit rate, 48 kHz sampling frequency)
Audio functions:
- Lo-Cut filter, Auto Gain
Image functions:
- Digital zoom (×0.75/×0.85/×1.00/×1.30/×1.50),
- Scene selection (Auto / Concert Lighting / Night / Concert-Low Light / Dance Club / Jazz Club / Concert Hall / Rehearsal-Studio / Garage / Outdoor / Sunset)
Self-timer:
- (Off/3sec/5sec/10sec)
- Display: 2.0" full-color touchscreen LCD
INPUT: MIC
- Type: 120° A/B and 120° X/Y stereo
- Maximum sound pressure input: 140 dB SPL
- Input gain: -30 to +44 dB
INPUT: EXTERNAL INPUT
- Input connector: Stereo mini jack
- Input gain: –∞ to +26 dB
- Input impedance: 2 k Ω or more
- Supports plug-in power
OUTPUTS
- Output connector: Combined line/headphones stereo mini jack
- HDMI connector: Micro Type D
- Built-in speaker: 400 mW 8 Ω mono speaker
USB: Operation as mass storage
- Class: USB 2.0 High Speed
USB: Operation as audio interface
- Class: USB 2.0 Full Speed
Specifications:
- 44.1 kHz sampling rate, 16-bit
- USB: Operation as webcam
Specifications:
- WVGA/720p video size,
- 48 kHz / 16-bit audio
- Note: Audio interface and mass storage operation with iPad is supported.
- Note: USB bus power supported
GENERAL
- Power supply:
- Lithium-ion battery: DC 4.2V maximum voltage,
- DC 3.7V nominal voltage, 1,050mAh capacity
AC adapter: ZOOM AD-17, sold separately: DC 5V/1A
Recharging times:
- Using USB: about 3 hours
- Using ZOOM AD-17: about 2 hours
- Battery operation time: About 3 hours or more
(when recording 720p/30 fps video with LCD closed)
External dimensions:
- Main unit (mic stored): 119 (length) × 51 (width) × 62 (height) mm
- Main unit (mic extended): 119 (length) × 39 (width) × 86 (height) mm
Weight:
- 6.0 oz / 178.6 grams with battery
- 5.5 oz / 155.9 grams without battery
