Warm audio WA 12 MKII Black

  • Read reviews (0)
  • Related accessories
  • Similar products
  • Warm Audio Wa 12 Mkii Black - Preamp - Main picture
  • Warm Audio Wa 12 Mkii Black - Preamp - Variation 1
682.80 €
513,00 €
  • Free delivery
  • Low prices guaranteed
  • Satisfied or refunded
  • 3-years warranty
  • Ref : 95651
In stock
shipped under 3/5 days
Stock in store
Not available in store

The brand Warm audio

Learn more about the Warm audio brand and discover the entire catalog.

The largest network of stores in France

Find all the information on our superstores and our specialized boutiques.

Contact an expert

Our musician and enthusiast tele-consultants are here to answer all your questions.

Preamp

The Warm Audio WA12 MKII black is a discrete mic/inst/line preamplifier.


The WA12 is a microphone preamplifier with a high-voltage circuit that is completely discrete and equipped with two transformers. It offers a high gain level (+71 dB), a large power reserve, a low noise level, and excellent sound performance, making it suitable for all recording applications.

- 71 dB of gain.
- Custom-made CineMag input and output transformers in the U.S.A.
- Input impedance switchable between 600 and 150 ohms (Tone button) to change the sound of the microphone and instrument inputs
- Fully discrete circuit
- High voltage operational amplifier type 1731
- Phantom power +48V
- Mic input on XLR and balanced jack
- Doubled output on XLR and balanced jacks
- High impedance instrument input (2 Mohms) on the front panel. The instrument signal passes through the entire circuit, including the two CineMag transformers and the discrete operational amplifier. This input is ideal for guitar, bass, keyboards, and more.
- Output level attenuation control (after the transformer), so you can saturate the preamp and transformer.
- 20dB Pad Pad control (Pad button)
- External mains transformer to lower the noise level
Lire la suite

Technical sheet

  • Type of preamp Transistor
  • UTILIZES PREMIUM-GRADE INPUT AND OUTPUT TRANSFORMERS FROM CINEMAG USA
  • FULLY DISCRETE DESIGN WITH A ROBUST 71DB OF GAIN
  • UTILIZES A DISCRETE 6-PIN SOCKETED 1731-STYLE OPAMP, WHICH CAN BE SWAPPED WITH OTHER DESIGNS THAT CONFORM TO THE 6-PIN, 2520 FOOTPRINT +/- 16VDC STANDARD FOR VARYING TONE AND FLAVOR
  • 20DB PAD.
  • TONE BUTTON - SWITCHES THE INPUT IMPEDANCE FROM 150 TO 600 OHMS AND CHANGES THE TONE OF BOTH THE MIC AND HI-Z INPUTS
  • MIC LEVEL BALANCED INPUT: XLR
  • 2 MEGOHM TRUE HI-Z INPUT ON THE FRONT PANEL WHICH SENDS THE SIGNAL THROUGH THE ENTIRE CIRCUIT, INCLUDING BOTH CINEMAG TRANSFORMERS AND THE X731 OPAMP - GREAT FOR GUITARS, BASS, KEYS, KEYBOARDS AND ANY INSTRUMENT WITH A 1/4” OUTPUT JACK
  • BALANCED OUTPUTS: XLR AND 1/4?/TRS
  • 48 VOLT PHANTOM POWER
  • LED METER GAIN INDICATION
  • OUTPUT ATTENUATION CONTROL (POSITIONED AFTER THE CINEMAG OUTPUT TRANSFORMER) ALLOWS FOR DRIVING THE PREAMP AND TRANSFORMERS INTO SATURATION
  • SWITCHABLE 115/230 VOLT IEC POWER INLET
